Victron Solar Panel 60W-12V Poly 545x668x25mm
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The BlueSolar Panels require exceptionally low light output and have high sensitivity to light. This 60W polycrystalline solar panel is designed for optimal performance in various conditions.
Specifications include a junction box type of PV-LH0801 and a PV cable connection type of No Cable. The panel dimensions are 668 mm in width, 545 mm in height, and 25 mm in depth, with a weight of 4 kg. The frame is made of durable aluminium.
It features a nominal power output of 60 W ±3%, an open-circuit voltage (Voc) of 23.1 V, and a maximum power voltage (Vmpp) of 19.3 V. The panel operates efficiently within a temperature range of -40 to 85 °C.
Key Features
- Nominal Power: 60W ±3%
- Dimensions: 545mm x 668mm x 25mm
- Durable Aluminium Frame
- Operating Temperature Range: -40°C to 85°C
- Product Warranty: 5 years
- 80% Power Output Warranty: 10 years
Specifications
| Brand | Victron |
| EAN | 8719076040408 |
| Type | Solar Battery |
| Sub-Type | solar_storage |
| Custom Bundle | No |
| Junction box type | PV-LH0801 |
| PV cable connection type | No Cable |
| Item Width | 668 mm |
| Weight | 4 kg |
| Item Height | 545 mm |
| Frame | Aluminium |
| Item Depth | 25 mm |
| Smallest packaging unit | 1 |
| Warranty on on elctrical performance 80% power output | 10 y |
| Warranty on elctrical performance 90% power output | 10 y |
| Number of panels per pallet | 140 |
| Product warranty | 5 y |
| Operating temperature range | [-40, 85] °C |
| Allowable hail load, weight | 7.53 g |
| Open -circuit voltage (Voc) | 23.1 V |
| Number of cells in series | 36 |
| Nominal Power ±3% (Pmpp) | 60 W |
| Maximum system voltage | 1,000 V |
| Maximum power voltage (Vmpp) | 19.3 V |
| Maximum power current (Impp) | 3.12 A |
| Cell type | Polycrystalline |
| Allowable hail load, speed | 23 m/s |
| Temperature coefficient Voc | -0.35 %/°C |
| Temperature coefficient MPP | -0.45 %/°C |
| Temperature coefficient Isc | 0.04 %/°C |
| Surface maximum load capacity | 200 kg/m² |
| Short-circuit current (ICS) | 3.37 A |
| PV output tolerance | 3 % |
| Voltage | 12V |
| Power Source | Battery |
| Application | Bodyshop |
| Manufacturer Part Number (MPN) | SPP040601200 |
