Description
The BlueSolar Panels require exceptionally low light output and have high sensitivity to light.
Specifications include a PV cable connection type of No Cable and a Junction box type of PV-LH0806. The panel has a height of 425 mm, depth of 25 mm, and width of 668 mm, with a weight of 3.1 kg.
This solar panel offers a nominal power of 45 W ±3% (Pmpp) and operates with an open-circuit voltage (Voc) of 22.9 V. It has a maximum power voltage (Vmpp) of 19.1 V and a maximum power current (Impp) of 2.36 A.
It is designed to withstand an operating temperature range of [-40, 85] °C, with a surface maximum load capacity of 200 kg/m². The panel features a product warranty of 5 years and warranties on electrical performance for 80% and 90% power output for 10 years each.
Key Features
- High-efficiency 45W polycrystalline solar panel
- Compact size: 425mm x 668mm x 25mm
- Durable aluminium frame
- Wide operating temperature range: -40 to 85 °C
- 10-year warranty on electrical performance
- Lightweight at only 3.1 kg
Specifications
| Brand | Victron |
| EAN | 8719076046356 |
| Type | Solar Battery |
| Sub-Type | solar_storage |
| Custom Bundle | No |
| PV cable connection type | No Cable |
| Junction box type | PV-LH0806 |
| Item Height | 425 mm |
| Frame | Aluminium |
| Item Depth | 25 mm |
| Item Width | 668 mm |
| Weight | 3.1 kg |
| Smallest packaging unit | 1 |
| Warranty on on elctrical performance 80% power output | 10 y |
| Warranty on elctrical performance 90% power output | 10 y |
| Product warranty | 5 y |
| Number of panels per pallet | 200 |
| Open -circuit voltage (Voc) | 22.9 V |
| Operating temperature range | [-40, 85] °C |
| Short-circuit current (ICS) | 2.55 A |
| PV output tolerance | 3 % |
| Allowable hail load, speed | 23 m/s |
| Allowable hail load, weight | 7.53 g |
| Cell type | Polycrystalline |
| Maximum power current (Impp) | 2.36 A |
| Maximum power voltage (Vmpp) | 19.1 V |
| Maximum system voltage | 2.55 V |
| Nominal Power ±3% (Pmpp) | 45 W |
| Number of cells in series | 36 |
| Temperature coefficient Voc | -0.35 %/°C |
| Temperature coefficient MPP | -0.45 %/°C |
| Temperature coefficient Isc | 0.04 %/°C |
| Surface maximum load capacity | 200 kg/m² |
| Voltage | 12V |
| Power Source | Battery |
| Application | Electrical |
| Manufacturer Part Number (MPN) | SPP040451200 |
