Victron Solar Panel 20W 12V Polycrystalline 440x350x25mm
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The BlueSolar Panels require exceptionally low light output and have high sensitivity to light. This 20W solar panel is designed for optimal performance in various environmental conditions, making it a reliable choice for solar energy applications.
With a nominal power output of 20W ±3%, this panel features a polycrystalline cell type and is constructed with an aluminium frame for durability. It has a compact design with dimensions of 440 mm in height, 350 mm in width, and a depth of 25 mm.
The panel operates efficiently across a wide temperature range of -40 to 85 °C and has a maximum system voltage of 1,000 V. It also boasts a short-circuit current of 1.18 A and a maximum power voltage of 18.4 V.
Key Features
- Nominal Power: 20W ±3%
- Dimensions: 440mm x 350mm x 25mm
- Durable aluminium frame
- Wide operating temperature range: -40 to 85 °C
- 10-year warranty on electrical performance at 90% power output
- Polycrystalline cell type for high efficiency
Specifications
| Brand | Victron |
| EAN | 8719076040392 |
| Type | Solar Battery |
| Sub-Type | solar_storage |
| Custom Bundle | No |
| Junction box type | PV-LH0805 |
| PV cable connection type | No Cable |
| Item Depth | 25 mm |
| Frame | Aluminium |
| Item Height | 440 mm |
| Weight | 1.9 kg |
| Item Width | 350 mm |
| Warranty on elctrical performance 90% power output | 10 y |
| Number of panels per pallet | 380 |
| Warranty on on elctrical performance 80% power output | 10 y |
| Product warranty | 5 y |
| Smallest packaging unit | 1 |
| Nominal Power ±3% (Pmpp) | 20 W |
| Temperature coefficient Voc | -0.35 %/°C |
| Temperature coefficient MPP | -0.45 %/°C |
| Temperature coefficient Isc | 0.04 %/°C |
| Surface maximum load capacity | 200 kg/m² |
| Short-circuit current (ICS) | 1.18 A |
| PV output tolerance | 3 % |
| Operating temperature range | [-40, 85] °C |
| Open -circuit voltage (Voc) | 21.96 V |
| Number of cells in series | 36 |
| Maximum system voltage | 1,000 V |
| Maximum power voltage (Vmpp) | 18.4 V |
| Maximum power current (Impp) | 1.09 A |
| Cell type | Polycrystalline |
| Allowable hail load, weight | 7.53 g |
| Allowable hail load, speed | 23 m/s |
| Voltage | 12V |
| Power Source | Battery |
| Application | Bodyshop |
| Manufacturer Part Number (MPN) | SPP040201200 |
