Victron Solar Panel 175W-12V Poly 1485x668x30mm
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The BlueSolar Panels require exceptionally low light output and have high sensitivity to light. This 175W solar panel features a robust aluminium frame, making it ideal for outdoor applications.
Specifications include a junction box type of PV-LH0808 and a PV cable length of 900 mm. The panel measures 1,485 mm in height, 668 mm in width, and 30 mm in depth, with a weight of 12 kg.
This solar panel offers a warranty on electrical performance of 90% power output for 10 years and 80% power output for 10 years, along with a product warranty of 5 years. It can withstand an allowable hail load speed of 23 m/s.
With a nominal power of 175 W ±3%, the panel operates efficiently across a temperature range of -40 to 85 °C. It features 36 cells in series and supports a maximum system voltage of 1,000 V.
Key Features
- Nominal Power: 175W ±3%
- Dimensions: 1485mm x 668mm x 30mm
- Durable aluminium frame
- Operating temperature range: -40 to 85 °C
- 5-year product warranty
- 10-year warranty on electrical performance (90% output)
Specifications
| Brand | Victron |
| EAN | 8719076040545 |
| Type | Solar Battery |
| Sub-Type | solar_storage |
| Custom Bundle | No |
| Junction box type | PV-LH0808 |
| PV cable length | 900 mm |
| Frame | Aluminium |
| Item Height | 1,485 mm |
| Item Depth | 30 mm |
| Item Width | 668 mm |
| Weight | 12 kg |
| Warranty on elctrical performance 90% power output | 10 y |
| Number of panels per pallet | 48 |
| Smallest packaging unit | 1 |
| Warranty on on elctrical performance 80% power output | 10 y |
| Product warranty | 5 y |
| Allowable hail load, speed | 23 m/s |
| Nominal Power ±3% (Pmpp) | 175 W |
| Temperature coefficient Isc | 0.04 %/°C |
| Surface maximum load capacity | 200 kg/m² |
| Short-circuit current (ICS) | 10.24 A |
| PV output tolerance | 3 % |
| Temperature coefficient Voc | -0.35 %/°C |
| Operating temperature range | [-40, 85] °C |
| Open -circuit voltage (Voc) | 21.9 V |
| Number of cells in series | 36 |
| Maximum system voltage | 1,000 V |
| Maximum power voltage (Vmpp) | 18.3 V |
| Maximum power current (Impp) | 9.56 A |
| Cell type | Polycrystalline |
| Allowable hail load, weight | 7.53 g |
| Temperature coefficient MPP | -0.45 %/°C |
| Voltage | 12V |
| Power Source | Battery |
| Application | Bodyshop |
| Manufacturer Part Number (MPN) | SPP041751200 |
