Victron Solar Panel 150W-12V Mono 1485x668x30mm
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The BlueSolar Panels require exceptionally low light output and have high sensitivity to light. This solar panel is designed to provide reliable energy even in low-light conditions.
It features a robust aluminium frame and is built to withstand harsh weather conditions, with a maximum surface load capacity of 200 kg/m². The panel is equipped with a junction box type PV-LH0808-1 and has a PV cable length of 900 mm.
With a nominal power output of 130 W and a maximum power voltage of 18.64 V, this panel is suitable for various solar applications. It also comes with a product warranty of 5 years and an electrical performance warranty of 10 years for 80% and 90% power output.
Key Features
- Nominal Power: 130W with ±3% tolerance
- Dimensions: 1485mm x 668mm x 30mm
- Durable aluminium frame for enhanced longevity
- Operating temperature range: -40 to 85 °C
- Maximum system voltage: 1,000 V
- Short-circuit current (ICS): 7.35 A
Specifications
| Brand | Victron |
| EAN | 8719076064220 |
| Type | Solar Battery |
| Sub-Type | solar_storage |
| Custom Bundle | No |
| Junction box type | PV-LH0808-1 |
| PV cable length | 900 mm |
| Weight | 9.1 kg |
| Item Width | 668 mm |
| Item Height | 1,200 mm |
| Frame | Aluminium |
| Item Depth | 30 mm |
| Warranty on on elctrical performance 80% power output | 10 y |
| Warranty on elctrical performance 90% power output | 10 y |
| Smallest packaging unit | 1 |
| Product warranty | 5 y |
| Number of panels per pallet | 36 |
| Allowable hail load, speed | 23 m/s |
| Allowable hail load, weight | 7.53 g |
| Temperature coefficient Isc | 0.04 %/°C |
| Temperature coefficient Voc | -0.35 %/°C |
| Temperature coefficient MPP | -0.45 %/°C |
| Surface maximum load capacity | 200 kg/m² |
| Short-circuit current (ICS) | 7.35 A |
| PV output tolerance | 3 % |
| Operating temperature range | [-40, 85] °C |
| Open -circuit voltage (Voc) | 22.83 V |
| Number of cells in series | 36 |
| Nominal Power ±3% (Pmpp) | 130 W |
| Maximum system voltage | 1,000 V |
| Maximum power voltage (Vmpp) | 18.64 V |
| Maximum power current (Impp) | 6.98 A |
| Cell type | Polycrystalline |
| Voltage | 12V |
| Power Source | Battery |
| Application | Bodyshop |
| Manufacturer Part Number (MPN) | SPM041501200 |
