Description
The Victron SmartSolar MPPT 75/10 is designed to maximize energy harvest and intelligently drive it to achieve a full charge in the shortest possible time. This solar charge controller is equipped with Bluetooth for easy monitoring and management of your solar power system.
With a rated charge current of 10 A, it supports nominal PV power of 145 W at 12 V and 290 W at 24 V. The device features multiple protections including automatic load disconnect, excessive temperature, output short-circuit, and PV reverse polarity, ensuring safe and efficient operation.
Its compact design measures 113 mm in width, 100 mm in height, and 40 mm in depth, making it suitable for various installations. The controller operates within a temperature range of -30°C to 60°C and has a maximum efficiency of 98%.
Key Features
- Bluetooth connectivity for remote monitoring
- Rated charge current of 10 A
- Supports nominal PV power of 145 W (12 V) and 290 W (24 V)
- Multiple safety protections included
- Compact design for easy installation
- IP43 rated for electronic components
Specifications
| Brand | Victron |
| EAN | 8719076040798 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| PV connection terminal type | Screw terminals 6 mm² (10 AWG) |
| Load connection terminal type | Screw terminals 6 mm² (10 AWG) |
| Battery connection terminal type | Screw terminals 6 mm² (10 AWG) |
| Weight | 0.5 kg |
| Item Width | 113 mm |
| Protection Category | IP22 (connection area),IP43 (electronic components) |
| Colour | Blue (RAL 5012) |
| Item Height | 100 mm |
| Item Depth | 40 mm |
| Safety | CSA C22.2,UL 1741,EN-IEC 62109-1 |
| Data Stored | Battery voltage,Battery current,Battery temperature,Load output Current,PV voltage,PV current |
| Data Retention Period | 46 d |
| Nominal PV power at 12 V | 145 W |
| Temperature Sensor | Optional (Smart Battery Sense) |
| Temperature Compensation at 24V | -32 mV/°C |
| Temperature Compensation at 12V | -16 mV/°C |
| Start-up PV DC voltage | The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V |
| Self-consumption - load on | 12V: 19mA / 24V: 16mA |
| Self-consumption - load off | 12V: 10mA / 24V: 8mA |
| Rated Charge Current | 10 A |
| Protections | Automatic load disconnect,Excessive temperature,Output short-circuit,PV reverse polarity |
| Operating temperature range | [-30, 60] °C |
| Number of trackers | 1 |
| Nominal PV power at 24 V | 290 W |
| Maximum PV short circuit current per tracker | 13 A |
| Maximum PV Open Circuit Voltage | 75 V |
| Maximum humidity (non-condensing) | 95 % |
| Maximum efficiency | 98 % |
| Max Continuous Load Current at 24V | 15 A |
| Max Continuous Load Current at 12V | 15 A |
| Low Voltage Load Reconnect | 13.1V / 26.2V or 14V / 28V or Battery Life algorithm |
| Low Voltage Load Disconnect | 11.1V / 22.2V or 11.8V / 23.6V or Battery Life algorithm |
| Data Communication | Bluetooth,VE.Direct |
| Charge voltage float | 13.8V / 27.6V (adjustable) |
| Charge voltage absorption | 14.4V / 28.8V (adjustable) |
| Charge algorithm | Multi-stage adaptive (adjustable) |
| Bluetooth | True |
| Battery voltage | 12V / 24V ( |
| Manufacturer Part Number (MPN) | SCC075010060R |
