Description
Disconnect the battery from non-essential loads before it is completely discharged with Victron Energy's Smart BatteryProtect. This device automatically detects the battery voltage (12V or 24V) and helps maintain battery health.
The Smart BatteryProtect features an alarm terminal, remote terminal, and battery/load terminals that utilize M6 bolts for secure connections. It has a compact design with dimensions of 55 mm in width, 48 mm in height, and 106 mm in depth, making it suitable for various installations.
With an operating temperature range of -40 to 50 °C and an IP67 protection rating for electronic components, this device is built to withstand harsh conditions. It also includes Bluetooth functionality for easy monitoring.
Key Features
- Automatic voltage detection for 12V or 24V batteries
- Compact design with low current consumption
- IP67 rated for protection against dust and water
- Bluetooth connectivity for remote monitoring
- Maximum continuous load current rating of 65 A
- Alarm output and remote on/off terminal included
Specifications
| Brand | Victron |
| EAN | 8719076041238 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| Alarm Terminal | Screw terminal 3-pole |
| Remote Terminal | Screw terminal two pole |
| Battery and Load Terminals | M6 bolts |
| Protection category connection area | IP00 |
| Weight | 0.2 kg |
| Item Width | 55 mm |
| Protection category electronic components | IP67 |
| Item Height | 48 mm |
| Item Depth | 106 mm |
| Default threshold disengage at 12V | 10.5 V |
| Default threshold disengage at 24V | 21 V |
| Default threshold engage at 12V | 12 V |
| Default threshold engage at 24V | 24 V |
| Load disconnect delay (immediate if triggered by the VE.Bus BMS) | 90 s |
| Alarm output delay | 12 s |
| Battery voltage nominal | 12V or 24V (automatic detection) |
| Bluetooth | Yes |
| Current consumption when off or in low volate protection mode (Bluetooth on) | 0.9 mA |
| Current consumption when off or in low volate protection mode (Bluetooth off) | 0.7 mA |
| Current consumption when on (Bluetooth on) | 1.4 mA |
| Current consumption when on (Bluetooth off) | 1.2 mA |
| Protections | Output short-circuit |
| Remote On Off Terminal | True |
| Able to deal with reverse current | No |
| Load reconnect delay | 30 s |
| Maximum continuous load current rating up to 40°C | 65 A |
| Maximum continuous load current rating up to 60°C | 39 A |
| Maximum load on alarm output | 50 mA |
| Operating temperature range | [-40, 50] °C |
| Operating voltage range | [6, 35] V |
| Peak current rating (30 seconds) | 250 A |
| Voltage | 24V |
| Manufacturer Part Number (MPN) | BPR065022000 |
