Victron Phoenix Inverter 12/375 230V VE.Direct Schuko
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Inverters allow you to power domestic equipment requiring 230V/120V AC using leisure or automotive batteries rated at 12V, 24V or 48V DC. The Victron Phoenix Inverter 12/375 is designed to provide reliable power for your needs.
It features a Schuko (CEE 7/4) AC outlet socket and screw terminals for battery connections (10 mm² / 8 AWG). The inverter is equipped with a remote terminal and is protected with an IP21 rating.
With a compact design, it has dimensions of 165 mm width, 260 mm depth, and 86 mm height, weighing 3 kg. The inverter operates efficiently with a maximum efficiency of 89% and supports a continuous output power of 300W at 25°C.
Key Features
- Peak power rating of 700W
- Adjustable zero-load power in ECO mode (0.9W)
- Fully programmable with VE.Direct communication port
- Operating temperature range from -40°C to 65°C
- Multiple protections against DC ripple, high/low battery voltage, and overload
Specifications
| Brand | Victron |
| EAN | 8719076045366 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| AC outlet socket | Schuko (CEE 7/4) |
| Battery connection terminal type | Screw terminals 10 mm² (8 AWG) |
| Remote Terminal | Screw terminal two pole |
| Protection Category | IP21 |
| Item Height | 86 mm |
| Material | Steel chassis and plastic cover |
| Weight | 3 kg |
| Item Width | 165 mm |
| Colour | Blue (RAL 5012) |
| Item Depth | 260 mm |
| Automotive directive | ECE R10-4 |
| Safety | EN-IEC 60335-1,EN-IEC 62109-1,UL 458 |
| EMC | EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3 |
| Operating temperature range (fan assisted cooling) | [-40, 65] °C |
| Zero Load Power in ECO Mode (adjustable) | 0.9 W |
| Zero-load power | 5.6 W |
| Remote on/off terminal | True |
| Protections | Excessive DC ripple,High battery voltage,Low battery voltage,Output short-circuit,Over temperature,Overload |
| Power deration above 40°C | 1.25 % |
| Peak power rating | 700 W |
| Maximum humidity (non-condensing) | 95 % |
| Maximum efficiency | 89 % |
| Fully programable | True |
| Frequency ±0.1% (adjustable) | 50 Hz |
| Eco mode stop and start power setting | Adjustable |
| ECO mode retry interval (adjustable) | 2.5 s |
| Dynamic (load dependent) low DC shutdown (configurable) | True |
| DC low shut down (adjustable) | 9.3 V |
| DC low restart and alarm (adjustable) | 10.9 V |
| DC input voltage range | [9.2, 17] V |
| Continuous power at 40°C | 260 W |
| Continuous inverter AC output power at 25°C | 300 W |
| Continuous power at 25°C (Nonlinear load, crest factor 3:1) | 375 VA |
| Communication Port | VE.Direct |
| Batery voltage nominal | 12 V |
| Battery charged detection voltage (adjustable) | 14 V |
| AC output voltage ±3% (adjustable) | 230 V |
| Voltage | 230V |
| Power Source | Mains |
| Application | Automotive |
| Manufacturer Part Number (MPN) | PIN121371200 |
