Victron Orion-Tr 48/48-2.5A Isolated DC-DC Converter
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Provide a stable DC output voltage using the easy to install Orion DC-DC Inverter from Victron Energy. This unit is designed for reliable performance in various applications, ensuring a consistent power supply.
The Orion-Tr features a remote on/off terminal connection with screw terminals, making it user-friendly for installation. It has a compact design with dimensions of 113 mm in width, 100 mm in height, and 47 mm in depth.
This converter operates efficiently with a maximum output current of 3 A and can handle continuous output power of 120 W at 25°C. It is also equipped with several protective features including over temperature and short-circuit protection.
Key Features
- Stable output voltage of 48.2 V with a tolerance of 200 mVrms
- Maximum efficiency of 89% and can operate in temperatures ranging from -20°C to 55°C
- Parallelable for increased output capabilities
- IP43 protection category for electronic components
- Compact size and lightweight at 0.42 kg for easy installation
Specifications
| Brand | Victron |
| EAN | 8719076016786 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| Remote On Off Terminal Connection | Screw terminal two pole |
| DC connection terminal type | Screw terminals 6 mm² (10 AWG) |
| Item Width | 113 mm |
| Weight | 0.42 kg |
| Protection Category | IP43 (electronic components) |
| Item Height | 100 mm |
| Item Depth | 47 mm |
| Colour | Blue (RAL 5012) |
| Safety | EN 60950 |
| Immunity | EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Emission | EN 55014-1,EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-5 |
| Under voltage shutdown | 28 V |
| Under voltage restart | 30 V |
| Output Voltage Tolerance | 200 mVrms |
| Maximum efficiency | 89 |
| Maximum humidity (non-condensing) | 95 % |
| Maximum output current | 3 A |
| Maximum continuous short-circuit current | 17 A |
| No-load current consumption | 80 mA |
| Operating temperature rang | [-20, 55] °C |
| Output voltage | 48.2 V |
| Output Voltage Noise | 2 mVrms |
| Output voltage range | [40, 60] V |
| Parallelable | True |
| Protections | Over temperature,Short-circuit proof |
| Remote on/off terminal | True |
| Standby current Consumption | 0.2 mA |
| Continuous output power at 40°C | 85 W |
| Continuous output power at 25°C | 120 W |
| Continuous Output Current Rating up to 25°C | 2.5 A |
| Galvanic isolation | True |
| Input voltage range | [32, 70] V |
| Isolation | 200 VDC |
| Manufacturer Part Number (MPN) | ORI484810110 |
