Victron Orion-Tr 24/12-20 DC-DC Converter 240W
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Provide a stable DC output voltage with the easy to install Orion DC-DC Inverter from Victron Energy. This converter is designed for efficient power management, ensuring reliable performance in various applications.
Specifications include a DC connection terminal type of screw terminals 6 mm² (10 AWG), a width of 94 mm, height of 73 mm, and depth of 45 mm. It weighs 0.25 kg and features a protection category of IP43.
The Orion-Tr operates within an input voltage range of [18, 35] V and provides a continuous output current of 20 A at an output voltage of 12.5 V. It has a maximum efficiency of 97% and is capable of operating in temperatures ranging from -20 to 55 °C.
Key Features
- Continuous output current of 20 A
- Input voltage range: [18, 35] V
- Maximum efficiency of 97%
- IP43 protection for durability
- Compact size: 94 mm x 73 mm x 45 mm
- Lightweight at 0.25 kg
Specifications
| Brand | Victron |
| EAN | 8719076023005 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| DC connection terminal type | Screw terminals 6 mm² (10 AWG) |
| Item Width | 94 mm |
| Weight | 0.25 kg |
| Protection Category | IP43 |
| Item Height | 73 mm |
| Item Depth | 45 mm |
| Colour | Blue (RAL 5012) |
| Safety | EN 60950 |
| Emission | EN 55014-1,EN-IEC 61000-6-3 |
| Immunity | EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Output derating above 40°C per °C | 3 % |
| Off load current | 35 |
| Output voltage | 12.5 V |
| Operating temperature rang | [-20, 55] °C |
| Maximum efficiency | 97 |
| Input voltage range | [18, 35] V |
| Continuous output current | 20 A |
| Manufacturer Part Number (MPN) | ORI241220200R |
