Victron Orion-Tr 24/12-10 DC-DC Converter 120W
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Provide a stable DC output voltage with the easy to install Orion DC-DC Inverter from Victron Energy. This converter is designed to ensure a reliable power supply for various applications.
The Orion-Tr model features a continuous output current of 10 A and an output voltage of 12.5 V. It operates efficiently within an input voltage range of 18 to 35 V and boasts a maximum efficiency of 97%.
With a compact design, the converter measures 94 mm in width, 73 mm in height, and 37 mm in depth, making it suitable for tight spaces. It is also lightweight, weighing only 0.2 kg.
Built to last, the Orion-Tr has a protection category of IP43, ensuring it is resistant to dust and water splashes. It adheres to safety standards including EN 60950 and automotive directive ECE R10-6.
Key Features
- Continuous output current of 10 A
- Input voltage range: 18-35 V
- Maximum efficiency of 97%
- Compact dimensions: 94 x 73 x 37 mm
- Protection category IP43
- Lightweight at only 0.2 kg
Specifications
| Brand | Victron |
| EAN | 8719076022893 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| DC connection terminal type | Screw terminals 6 mm² (10 AWG) |
| Colour | Blue (RAL 5012) |
| Item Depth | 37 mm |
| Weight | 0.2 kg |
| Item Height | 73 mm |
| Protection Category | IP43 |
| Item Width | 94 mm |
| Safety | EN 60950 |
| Immunity | EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Emission | EN 55014-1,EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-6 |
| Output derating above 40°C per °C | 3 % |
| Output voltage | 12.5 V |
| Operating temperature rang | [-20, 55] °C |
| Off load current | 45 |
| Maximum efficiency | 97 |
| Input voltage range | [18, 35] V |
| Continuous output current | 10 A |
| Manufacturer Part Number (MPN) | ORI241210200R |
