Victron Orion IP67 24/12-5A DC-DC Converter
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Victron Orion IP67 DC-DC Converter is a completely encapsulated device that is waterproof, shockproof, and ignition protected. This ensures that water, oil, or dirt will not damage the unit, making it ideal for various outdoor applications.
With an input voltage range of 15 to 40 V and an output voltage of 12 V, this converter is designed for reliable performance. It features two 1.8m input and output cables with a 0.8 mm² (18 AWG) gauge for easy installation.
Constructed from durable aluminium and rated IP67 for protection against dust and water, the Orion converter operates efficiently across a wide temperature range of -40 to 70 °C. It also includes multiple safety features, such as overload protection, short-circuit proofing, and reverse polarity protection.
Key Features
- Waterproof and shockproof design (IP67)
- Input voltage range: 15-40 V
- Output voltage: 12 V
- Maximum efficiency: 93%
- Operating temperature range: -40 to 70 °C
- Includes two 1.8m cables (0.8 mm²)
Specifications
| Brand | Victron |
| EAN | 8719076048428 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| DC connection terminal type | Two 1.8m input and output cables 0.8 mm² (18 AWG) |
| Item Width | 43 mm |
| Colour | Blue (RAL 5012) |
| Weight | 0.05 kg |
| Item Depth | 20 mm |
| Item Height | 25 mm |
| Material | Aluminium |
| Protection Category | IP67 |
| Vibration | IEC68-2-6:10-150Hz/1.0G |
| Emission | EN 55014-1,EN-IEC 61000-6-3 |
| Immunity | EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Safety | EN 60950 |
| Input voltage range | [15, 40] V |
| Under voltage restart | 14 V |
| Under voltage shutdown | 13 V |
| Ripple and noise | 0.075 Vmpp |
| Protections | Overload,Short-circuit proof,Reverse polarity (fuse),Over temperature |
| Output Voltage Tolerance | 3 % |
| Output voltage | 12 V |
| Output derating above 40°C per °C | 3 % |
| Operating temperature rang | [-40, 70] °C |
| No-load current consumption | 1 mA |
| Maximum efficiency | 93 |
| Manufacturer Part Number (MPN) | ORI241205260 |
