Victron Cyrix-Li-load 12/24V-230A Intelligent Load Relay
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Victron Cyrix-Li-load is an intelligent load relay designed to automatically connect batteries in parallel when one of them has reached a pre-set voltage. This device is ideal for use in various power applications, ensuring reliable battery management.
With an IP54 protection category, the Cyrix is well-suited for outdoor environments where it may be exposed to dust and moisture. It features a compact design with dimensions of 100 mm width, 65 mm height, and 50 mm depth, making it easy to install in tight spaces.
This relay supports automatic detection of 12V or 24V nominal battery voltages and has a continuous current and breaking capacity of 230 A. An LED status indication helps users monitor the relay's operation effectively.
Key Features
- Automatic detection of 12V or 24V battery voltage
- Continuous current capacity of 230 A
- IP54 rated for dust and moisture resistance
- LED status indication for easy monitoring
- Includes 1m control cable for installation
- Low current consumption of 4 mA when open
Specifications
| Brand | Victron |
| EAN | 8719076022244 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| Protection Category | IP54 |
| Item Depth | 50 mm |
| Item Height | 65 mm |
| Weight | 0.27 kg |
| Item Width | 100 mm |
| Nominal Battery Voltage | 12V or 24V (automatic detection) |
| LED Status Indication | True |
| Current Consumption when Open | 4 mA |
| Control input | The Cyrix engages when the control input is high (appr. Battery voltage) The Cyrix disengages when the control input is left free floating or pulled low |
| Control Cable Included (1m) | True |
| Continuous current and breaking capacity at 12 or 24V | 230 A |
| Connect/disconnect profiles | See our website |
| Voltage | 24V |
| Manufacturer Part Number (MPN) | CYR010230450 |
