Victron BlueSolar PWM-Pro Charge Controller 12/24V 30A
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Charge batteries in three phases and protect them against overload and short-circuiting with the BlueSolar PWM. This charge controller is designed for 12V and 24V systems, with automatic detection of battery voltage.
It features screw terminals for PV, load, and battery connections, ensuring a secure and reliable setup. The device operates within a temperature range of -20 to 50 °C and is protected against battery reverse polarity, output short-circuit, and excessive temperature.
With a rated charge current of 30A, the BlueSolar PWM-Pro is suitable for use with solar panels configured for both 12V and 24V systems. It also includes features like low voltage load disconnect and manual control for load output.
Key Features
- Rated charge current: 30A
- Automatic detection for 12V and 24V battery systems
- IP30 protection category
- Temperature compensation for optimal battery performance
- Manual control and low voltage disconnect for load output
- Compatible with optional remote panel
Specifications
| Brand | Victron |
| EAN | 8719076025399 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| PV connection terminal type | Screw terminals 10 mm² (8 AWG) |
| Load connection terminal type | Screw terminals 10 mm² (8 AWG) |
| Battery connection terminal type | Screw terminals 10 mm² (8 AWG) |
| Weight | 0.5 kg |
| Item Width | 100 mm |
| Protection Category | IP30 |
| Item Height | 200 mm |
| Item Depth | 57 mm |
| Colour | Grey |
| Safety | EN-IEC 62109-1 |
| Emission | EN-IEC 61000-6-1,ISO 7637-2,EN-IEC 61000-6-3 |
| Self-consumption | 10 mA |
| Temperature Compensation | -30 mV / °C resp. -60 mV / °C (if temperature sensor installed) |
| Temperature Sensor | Yes, optional (artice SCC940100100) |
| Low Voltage Load Reconnect | 12.6V / 25.2V |
| automatic Load Disconnect | True |
| Battery voltage | 12V / 24V (automatic detection) |
| Charge voltage absorption | 14.4V / 28.8V |
| Charge voltage equalzation | 14.6V / 29.2V |
| Charge voltage float | 13.8V / 27.6V |
| grounding | Common positive |
| Load Output | Manual control + low voltage disconnect |
| Low Voltage Load Disconnect | 11.1V / 22.2V |
| Remote panel | Optional (article SCC900300000) |
| Maximum humidity (non-condensing) | 98 % |
| Maximum Solar voltage | 28V / 55V |
| Operating temperature range | [-20, 50] °C |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Excessive temperature |
| PV array 12V | Solar panel with 36 cells |
| PV array 24V | Solar panel with 72 cells,Two solar panles with 36 cells in series |
| Rated Charge Current | 30 A |
| Voltage | 24V |
| Manufacturer Part Number (MPN) | SCC010030010 |
Downloads
- 20140527 Press Release Intersolar
- Bluesolar Pwm Light And Duo Charge Controllers 2021 12 29
- Bluesolar Pwm Pro Charge Controllers 2022 07 04
- Datasheet Bluesolar Pwm Light Charge Controllers 12 24V En
- Datasheet Bluesolar Pwm Light Charge Controllers 48V En
- Datasheet Bluesolar Pwm Pro Charge Controllers En
