Victron BlueSolar PWM-Light Charge Controller 12/24V 5A
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Charge batteries in three phases and protect them against overload and short-circuiting with the BlueSolar PWM. This charge controller is suitable for both 12V and 24V systems, automatically detecting the battery voltage for ease of use.
The controller features screw terminals for battery, PV, and load connections, ensuring a secure and reliable setup. With a rated charge current of 5 A, it is designed to handle solar panels effectively, supporting configurations for both 12V and 24V solar arrays.
Designed for durability, the BlueSolar PWM-Light Charge Controller has a compact size with a depth of 33.5 mm, height of 70 mm, and width of 133 mm. It operates within a temperature range of -20 to 50 °C and has an IP20 protection category, making it suitable for indoor applications.
Key Features
- Rated charge current of 5 A for efficient battery charging.
- Automatic detection of 12V or 24V battery voltage.
- IP20 protection category for indoor use.
- Overload and short-circuit protection for safety.
- Compact dimensions: 33.5 mm depth, 70 mm height, 133 mm width.
- Manual control with low voltage disconnect for added functionality.
Specifications
| Brand | Victron |
| EAN | 8719076025245 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| Battery connection terminal type | Screw terminals 5 mm² (10 AWG) |
| PV connection terminal type | Screw terminals 5 mm² (10 AWG) |
| Load connection terminal type | Screw terminals 5 mm² (10 AWG) |
| Item Depth | 33.5 mm |
| Colour | Black |
| Item Height | 70 mm |
| Weight | 0.15 kg |
| Item Width | 133 mm |
| Protection Category | IP20 |
| Emission | EN-IEC 61000-6-1,ISO 7637-2,EN-IEC 61000-6-3 |
| Safety | EN-IEC 62109-1 |
| Overload Protection at 160% load | Shutdown after 5 seconds |
| Overload Protection Short Circuit | Immediate shutdown |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Excessive temperature |
| Rated Charge Current | 5 A |
| PV array 12V | Solar panel with 36 cells |
| PV array 24V | Solar panel with 72 cells,Two solar panles with 36 cells in series |
| Temperature Sensor | No |
| Temperature Compensation | -30 mV / °C resp. -60 mV / °C (if temperature sensor installed) |
| Self-consumption | 10 mA |
| Remote panel | No |
| Load Output | Manual control + low voltage disconnect |
| grounding | Common positive |
| Charge voltage float | 13.8V / 27.6V |
| Charge voltage absorption | 14.2V / 28.4V |
| Battery voltage | 12V / 24V (automatic detection) |
| automatic Load Disconnect | True |
| Overload Protection at 130% load | Shutdown after 60 seconds |
| Operating temperature range | [-20, 50] °C |
| Maximum Solar voltage | 28V / 55V |
| Maximum humidity (non-condensing) | 95 % |
| Low Voltage Load Reconnect | 12.6V / 25.2V (manual) 13.1V / 26.2V (automatic) |
| Low Voltage Load Disconnect | 11.2V / 22.4V |
| Voltage | 24V |
| Manufacturer Part Number (MPN) | SCC010005000 |
