Description
The Blue Smart IP67 Waterproof Charger is the new professional battery charger with built-in Bluetooth. It features a robust design and is suitable for various applications, including marine use.
This charger is equipped with a 1.5-meter cable with a BS 1363 plug (UK) for AC connection and red and black 1.5-meter cables with M8 eyelets for battery connection. It has a compact size with a depth of 65 mm, height of 99 mm, and width of 219 mm, weighing 2.4 kg.
With a protection category of IP67, this charger is designed to withstand harsh environments. It has a nominal battery voltage of 24V and can deliver a charge current of 12A, making it efficient for various battery types, including lithium.
Key Features
- Bluetooth connectivity for easy monitoring and control
- IP67 waterproof rating for reliable outdoor use
- Adaptive 5-stage charge algorithm for optimal battery care
- Programmable settings for customized charging
- Operating temperature range of -30 to 60 °C
- High efficiency of 96% with low power consumption
Specifications
| Brand | Victron |
| EAN | 8719076041092 |
| Type | Battery Charger |
| Sub-Type | charger |
| Custom Bundle | No |
| AC connection terminal type | Cable of 1.5 meter with BS 1363 plug (UK) |
| Battery connection terminal type | Red and black 1.5 meter cable with M8 eyelets |
| Weight | 2.4 kg |
| Item Depth | 65 mm |
| Item Height | 99 mm |
| Material | Aluminium |
| Protection category | IP67 |
| Colour | Blue (RAL 5012) |
| Item Width | 219 mm |
| Safety | EN-IEC 60335-1,EN-IEC 60335-2-29 |
| Emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| Immunity | EN 55014-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| AC input frequency range | [45, 65] Hz |
| AC input voltage Bucket | 230 V |
| AC input voltage range | [180, 265] VAC |
| Nominal battery voltage | 24 V |
| Bluetooth | True |
| Can be used as power supply | True |
| Charge algorithm | Adaptive, 5-stage |
| Charge Current Low Mode | 4 A |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Over temperature |
| Start interrupt option (Si) | Short circuit proof, 1V below main output, 0.5A current limit |
| Programable | True |
| Charge Current Normal Mode (Nominal Value) | 12 A |
| Charge voltage Absorption | Normal: 28.8V High: 29.4V Lithium: 28.4V |
| Charge voltage float | Normal: 27.6V High: 27.6V Li-ion: 27.0V |
| Charge voltage storage | Normal: 26.4V High: 26.4V Li-ion: 27.0V |
| Communication Ports | Bluetooth |
| Derating per °C above 40°C | 3 % |
| Efficiency | 96 % |
| Lithium compatible | True |
| Maximum humidity (non-condensing) | 100 % |
| No-load power consumption | 0.5 W |
| Number of charge outputs | 1 |
| Operating temperature range | [-30, 60] °C |
| Ouput fully rated up to | 40 °C |
| Voltage | 24V |
| Power Source | Mains |
| Manufacturer Part Number (MPN) | BPC241214006 |
