Victron Blue Smart IP65 Charger 12V 15A with Bluetooth
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Blue Smart IP65 Charger is the new professional battery charger with built-in Bluetooth. This charger is designed for 12V batteries and features a charge current of 15A, making it ideal for various applications.
It includes a red and black 1.5 meter cable with plugable M8 eyelets or clamps for battery connection, and a 1.5 meter cable with a BS 1363 plug for AC connection (UK). The charger is compact with dimensions of 190 mm in depth, 105 mm in width, and 60 mm in height, and it weighs 0.9 kg.
With an IP65 protection rating, this charger is resistant to dust and water, ensuring durability in outdoor conditions. It operates efficiently with a 94% efficiency rating and is compatible with lithium batteries.
Key Features
- Bluetooth connectivity for easy monitoring
- 15A charge current for fast charging
- IP65 rated for dust and water resistance
- Adaptive 7-stage charge algorithm
- Operating temperature range from -40°C to 60°C
- Battery reverse polarity and output short-circuit protections
Specifications
| Brand | Victron |
| EAN | 8719076039761 |
| Type | Battery Charger |
| Sub-Type | charger |
| Custom Bundle | No |
| Battery connection terminal type | Red and black 1.5 meter cable with plugable M8 eyelets or clamps |
| AC connection terminal type | Cable of 1.5 meter with BS 1363 plug (UK) |
| Item Depth | 190 mm |
| Protection category | IP65 |
| Item Width | 105 mm |
| Weight | 0.9 kg |
| Item Height | 60 mm |
| Immunity | EN 55014-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| Safety | EN-IEC 60335-1,EN-IEC 60335-2-29 |
| Temperature compensation (adjustable) | -16 mV/°C |
| Standby power consumption | 0.5 W |
| Protections | Battery reverse polarity,Output short-circuit,Over temperature |
| Programable | True |
| Power supply mode | True |
| Ouput fully rated up to | 30 °C |
| Operating temperature range | [-40, 60] °C |
| Back current drain per month | 0.7 Ah/mo |
| Back current drain | 1 mA |
| AC input voltage range | [180, 265] VAC |
| AC input voltage Bucket | 230 V |
| AC input frequency range | [45, 65] Hz |
| Charge voltage storage | Normal: 13.2V High: 13.2V Li-ion: 13.5V |
| Number of charge outputs | 1 |
| Maximum humidity (non-condensing) | 95 % |
| Lithium compatible | True |
| Efficiency | 94 % |
| Charge voltage float | Normal: 13.8V High: 13.8V Li-ion: 13.5V |
| Charge voltage Absorption | Normal: 14.4V High: 14.7V Lithium: 14.2V |
| Charge Current Normal Mode (Nominal Value) | 15 A |
| Charge Current Low Mode | 4 A |
| Charge algorithm | Adaptive, 7-stage |
| Bluetooth | Yes, -4dBm, 2402 – 2480 MHz |
| Nominal battery voltage | 12 V |
| Voltage | 12V |
| Colour | Blue |
| Power Source | Battery |
| Manufacturer Part Number (MPN) | BPC121531024R |
