Victron Blue Smart IP22 Charger 12V 20A
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Blue Smart IP22 Charger is the new professional battery charger with built-in Bluetooth. It is designed for 12V batteries and features a charge current of 20A in normal mode, with a low mode of 10A for night charging.
This charger includes a 1.8 meter (6 feet) cable with a US NEMA 5-15 plug for AC connection and screw terminals for battery connection (16 mm² / 6 AWG). It is constructed from durable aluminium and has a protection category of IP22, making it suitable for various environments.
With an efficiency of 93%, this charger is lithium compatible and features programmable settings. It also includes various safety protections such as battery reverse polarity and output short-circuit protection.
Additional features include Bluetooth communication ports, adjustable temperature compensation, and the ability to function as a power supply.
Key Features
- Charge current of 20A (10A in low mode)
- Bluetooth connectivity for easy monitoring
- IP22 protection category for durability
- Programmable settings and adaptive 6-stage charge algorithm
- Compatible with lithium batteries
- Safety features including reverse polarity protection
Specifications
| Brand | Victron |
| EAN | 8719076050605 |
| Type | Battery Charger |
| Sub-Type | charger |
| Custom Bundle | No |
| AC connection terminal type | Cable of 1.8 meter (6 feet) with US NEMA 5-15 plug |
| Battery connection terminal type | Screw terminals 16 mm² (6 AWG) |
| Weight | 1.3 kg |
| Colour | Blue (RAL 5012) |
| Item Depth | 65 mm |
| Item Height | 235 mm |
| Material | Aluminium |
| Protection category | IP22 |
| Item Width | 108 mm |
| Emission | EN 55014-1,EN-IEC 61000-6-3,EN-IEC 61000-3-2 |
| Immunity | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3, EN-IEC 61000-6-2 |
| Safety | CSA C22.2,EN-IEC 60335-1,EN-IEC 60335-2-29,UL 1236 |
| Automotive directive | ECE R10-5 |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Over temperature |
| Efficiency | 93 % |
| Forced cooling | True |
| Lithium compatible | True |
| Maximum humidity (non-condensing) | 98 % |
| No-load power consumption | 0.5 W |
| Number of charge outputs | 1 |
| Operating temperature range | [-20, 50] °C |
| Programable | True |
| Communication Ports | Bluetooth |
| Temperature Compensation (adjustable) | -16 mV/°C |
| Temperature Sensor | Optional (Smart Battery Sense) |
| AC input voltage Bucket | 120 V |
| AC input frequency range | [45, 65] Hz |
| Nominal battery voltage | 12 V |
| Bluetooth | True |
| Can be used as power supply | True |
| Charge algorithm | Adaptive, 6-stage |
| Charge Current Night or Low Mode | 10 A |
| Charge Current Normal Mode (Nominal Value) | 20 A |
| Charge voltage Absorption | Normal: 14.4V High: 14.7V Lithium: 14.2V |
| Charge voltage float | Normal: 13.8V High: 13.8V Li-ion: 13.5V |
| Charge voltage storage | Normal: 13.2V High: 13.2V Li-ion: 13.5V |
| Voltage | 12V |
| Power Source | Battery |
| Manufacturer Part Number (MPN) | BPC122045102 |
