Victron Blue Smart IP22 Charger 12V 15A with Bluetooth
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Blue Smart IP22 Charger is the new professional battery charger with built-in Bluetooth. It is designed for charging 12V batteries and features a programmable charge algorithm with six stages for optimal battery maintenance.
This charger has a maximum charge current of 15A and can also operate in a low mode with 7.5A. The unit is equipped with a 1.8-meter AC connection cable with a US NEMA 5-15 plug and features screw terminals for battery connections.
Constructed from durable aluminium, the charger is rated IP22 for protection against water and dust ingress. It can operate in temperatures ranging from -40°C to 60°C and has a maximum humidity tolerance of 98% (non-condensing).
Key Features
- Bluetooth connectivity for easy monitoring and control
- Programmable with an adaptive 6-stage charge algorithm
- IP22 rated for water and dust protection
- Operating temperature range of -40°C to 60°C
- Compatible with lithium batteries
- Forced cooling for enhanced performance
Specifications
| Brand | Victron |
| EAN | 8719076050582 |
| Type | Battery Charger |
| Sub-Type | charger |
| Custom Bundle | No |
| Battery connection terminal type | Screw terminals 16 mm² (6 AWG) |
| AC connection terminal type | Cable of 1.8 meter (6 feet) with US NEMA 5-15 plug |
| Protection category | IP22 |
| Material | Aluminium |
| Item Height | 235 mm |
| Item Depth | 65 mm |
| Colour | Blue (RAL 5012) |
| Item Width | 108 mm |
| Weight | 1.3 kg |
| Emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| Immunity | EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-3-3 |
| Safety | EN-IEC 60335-1,EN-IEC 60335-2-29,CSA C22.2,UL 1236 |
| Automotive directive | ECE R10-5 |
| AC input voltage Bucket | 120 V |
| Programable | True |
| Temperature Sensor | Optional (Smart Battery Sense) |
| Temperature Compensation (adjustable) | -16 mV/°C |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Over temperature |
| Operating temperature range | [-40, 60] °C |
| Number of charge outputs | 1 |
| No-load power consumption | 0.5 W |
| Maximum humidity (non-condensing) | 98 % |
| Lithium compatible | True |
| Can be used as power supply | True |
| Bluetooth | True |
| Nominal battery voltage | 12 V |
| AC input frequency range | [45, 65] Hz |
| Forced cooling | True |
| Efficiency | 93 % |
| Communication Ports | Bluetooth |
| Charge voltage storage | Normal: 13.2V High: 13.2V Li-ion: 13.5V |
| Charge voltage float | Normal: 13.8V High: 13.8V Li-ion: 13.5V |
| Charge voltage Absorption | Normal: 14.4V High: 14.7V Lithium: 14.2V |
| Charge Current Normal Mode (Nominal Value) | 15 A |
| Charge Current Night or Low Mode | 7.5 A |
| Charge algorithm | Adaptive, 6-stage |
| Voltage | 12V |
| Power Source | Battery |
| Manufacturer Part Number (MPN) | BPC121545102 |
