Victron Blue Smart IP22 Charger 12/30(3) 230V UK
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Blue Smart IP22 Charger is the new professional battery charger with built-in bluetooth. It features a robust design and is suitable for various battery types, including lithium. The charger has three outputs, allowing you to charge multiple batteries simultaneously.
It comes with a 1.5-meter cable with a BS 1363 plug (UK) and screw terminals for battery connections. The protection category is IP22, ensuring durability in various environments.
With an efficiency of 93% and a programmable charge algorithm, this charger is designed to optimize battery life. It operates within a temperature range of -20 to 50 °C and can handle a maximum humidity of 98% (non-condensing).
Key Features
- Bluetooth connectivity for easy monitoring
- Three charge outputs for multiple batteries
- Adaptive 6-stage charge algorithm
- IP22 protection for durability
- Programmable settings for customized charging
Specifications
| Brand | Victron |
| EAN | 8719076052425 |
| Type | Battery Charger |
| Sub-Type | charger |
| Custom Bundle | No |
| AC connection terminal type | Cable of 1.5 meter with BS 1363 plug (UK) |
| Battery connection terminal type | Screw terminals 16 mm² (6 AWG) |
| Protection category | IP22 |
| Weight | 1.3 kg |
| Item Width | 108 mm |
| Colour | Blue (RAL 5012) |
| Item Depth | 65 mm |
| Item Height | 235 mm |
| Material | Aluminium |
| Immunity | EN 55014-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Safety | EN-IEC 60335-1,EN-IEC 60335-2-29 |
| Automotive directive | ECE R10-5 |
| Emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| Efficiency | 93 % |
| Forced cooling | True |
| Lithium compatible | True |
| Maximum humidity (non-condensing) | 98 % |
| No-load power consumption | 0.5 W |
| Number of charge outputs | 3 |
| Operating temperature range | [-20, 50] °C |
| Programable | True |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Over temperature |
| Temperature Compensation (adjustable) | -16 mV/°C |
| Temperature Sensor | Optional (Smart Battery Sense) |
| AC input voltage Bucket | 230 V |
| AC input frequency range | [45, 65] Hz |
| Nominal battery voltage | 12 V |
| Bluetooth | True |
| Can be used as power supply | True |
| Charge algorithm | Adaptive, 6-stage |
| Charge Current Night or Low Mode | 15 A |
| Charge Current Normal Mode (Nominal Value) | 30 A |
| Charge voltage Absorption | Normal: 14.4V High: 14.7V Lithium: 14.2V |
| Charge voltage float | Normal: 13.8V High: 13.8V Li-ion: 13.5V |
| Charge voltage storage | Normal: 13.2V High: 13.2V Li-ion: 13.5V |
| Communication Ports | Bluetooth |
| Voltage | 230V |
| Power Source | Mains |
| Manufacturer Part Number (MPN) | BPC123048022 |
