Victron Blue Smart IP22 Charger 12/20(3) 230V UK
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Blue Smart IP22 Charger is the new professional battery charger with built-in Bluetooth. It is designed to charge 12V batteries and is equipped with advanced features for optimal battery management.
Specifications include a battery connection terminal type of screw terminals (16 mm² / 6 AWG) and an AC connection terminal type with a cable of 1.5 meters and a BS 1363 plug (UK). The charger weighs 1.3 kg and has dimensions of 108 mm width, 235 mm height, and 65 mm depth.
Constructed from durable aluminium, the charger is finished in a striking blue (RAL 5012) and has a protection category of IP22, making it suitable for various environments. It also features Bluetooth communication for easy monitoring and control.
Key Features
- Adaptive 6-stage charge algorithm for efficient battery charging
- Bluetooth connectivity for remote monitoring
- Compatible with lithium batteries
- Three charge outputs with a maximum charge current of 20A
- Protection against battery reverse polarity, output short-circuit, and over temperature
- Programmable settings for customized charging
Specifications
| Brand | Victron |
| EAN | 8719076041078 |
| Type | Battery Charger |
| Sub-Type | charger |
| Custom Bundle | No |
| Battery connection terminal type | Screw terminals 16 mm² (6 AWG) |
| AC connection terminal type | Cable of 1.5 meter with BS 1363 plug (UK) |
| Weight | 1.3 kg |
| Item Width | 108 mm |
| Material | Aluminium |
| Item Height | 235 mm |
| Item Depth | 65 mm |
| Colour | Blue (RAL 5012) |
| Protection category | IP22 |
| Immunity | EN 55014-2,EN-IEC 61000-3-3,EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
| Emission | EN 55014-1,EN-IEC 61000-3-2,EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-5 |
| Safety | EN-IEC 60335-1,EN-IEC 60335-2-29 |
| Lithium compatible | True |
| Forced cooling | True |
| Efficiency | 93 % |
| Communication Ports | Bluetooth |
| Maximum humidity (non-condensing) | 98 % |
| Charge voltage storage | Normal: 13.2V High: 13.2V Li-ion: 13.5V |
| Charge voltage float | Normal: 13.8V High: 13.8V Li-ion: 13.5V |
| Charge voltage Absorption | Normal: 14.4V High: 14.7V Lithium: 14.2V |
| Charge Current Normal Mode (Nominal Value) | 20 A |
| Charge Current Night or Low Mode | 10 A |
| Protections | Battery reverse polarity (fuse),Output short-circuit,Over temperature |
| Temperature Sensor | Optional (Smart Battery Sense) |
| Temperature Compensation (adjustable) | -16 mV/°C |
| Charge algorithm | Adaptive, 6-stage |
| Programable | True |
| Operating temperature range | [-20, 50] °C |
| Number of charge outputs | 3 |
| No-load power consumption | 0.5 W |
| Can be used as power supply | True |
| Bluetooth | True |
| Nominal battery voltage | 12 V |
| AC input voltage Bucket | 230 V |
| AC input frequency range | [45, 65] Hz |
| Voltage | 230V |
| Power Source | Mains |
| Manufacturer Part Number (MPN) | BPC122043022 |
