Description
Guarantee continuous DC power to mission-critical equipment with Argo Diode Battery Combiners. The Victron BCD 802 is designed to combine two batteries effectively, ensuring optimal performance and reliability.
This battery combiner features M6 bolt terminals for secure connections and is compact in size, measuring 120 mm in width, 75 mm in depth, and 60 mm in height. With a weight of only 0.8 kg, it is easy to install in various setups.
The Victron BCD 802 supports a maximum continuous current of 80 A and operates at a nominal battery voltage of either 12V or 24V, making it versatile for different applications.
Key Features
- Maximum continuous current: 80 A
- Nominal battery voltage: 12V or 24V
- Compact dimensions: 120 mm x 75 mm x 60 mm
- Lightweight design at 0.8 kg
- Secure M6 bolt battery terminals
Specifications
| Brand | Victron |
| EAN | 8719076020974 |
| Type | Leisure Battery |
| Sub-Type | leisure |
| Custom Bundle | No |
| Battery Terminals | M6 bolts |
| Item Depth | 75 mm |
| Item Height | 60 mm |
| Weight | 0.8 kg |
| Item Width | 120 mm |
| Maximum continuous current | 80 A |
| Nominal Battery Voltage | 12V or 24V |
| Number of batteries | 2 |
| Voltage | 12V |
| Power Source | Battery |
| Manufacturer Part Number (MPN) | BCD000802000 |
