Victron 12V/60Ah Gel Deep Cycle Battery
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
The Gel and AGM Batteries are particularly suitable for high current discharge applications such as for inverters, thrusters, and winches.
This Victron 12V Gel Deep Cycle Battery has a nominal capacity of 60 Ah, making it ideal for various leisure applications. It features flange terminals with M8 bolts for secure connections.
With a height of 227 mm, width of 138 mm, and length of 229 mm, this battery is designed for efficient space utilization. It has a weight of 20 kg, ensuring robust performance.
The battery technology is Flat plate GEL, with a sealed VLRA (Valve Regulated Lead Acid) type, ensuring safety and reliability.
Key Features
- Nominal voltage: 12V
- Nominal capacity: 60Ah at 20h discharge
- Long cycle life: up to 1,800 cycles at 30% discharge
- Cold cranking amps (CCA) at -18°C: 250A
- Float design life: 12 years at 20°C
- Recommended charge voltage absorption: [14.2, 14.6] V
Specifications
| Brand | Victron |
| EAN | 8719076037149 |
| Type | Leisure Battery |
| Sub-Type | leisure |
| Custom Bundle | No |
| Battery Nominal Capacity : Capacity 20h discharge at 25°C (77°F) | 60 Ah |
| Battery Voltage Nominal | 12 V |
| Battery Voltage Nominal Bucket | 12 |
| Terminal material | Copper |
| Battery terminals | Flange terminals with M8 bolts |
| Item Height | 227 mm |
| Item Width | 138 mm |
| Weight | 20 kg |
| length | 229 mm |
| Recommended Charge Voltage Absorption | [14.2, 14.6] V |
| Technology | Flat plate GEL (electrolyte is immobilized as gel) |
| Reserve Capacity (RES CAP) at 27°C (80°F) | 70 Ah |
| Recommended Charge Voltage Storage | [13.2, 13.5] V |
| Recommended Charge Voltage Float | [13.5, 13.8] V |
| Float design life | 12 years at 20°C |
| Cycle design life at 80% discharge | 500 cycles |
| Cycle design life at 50% discharge | 750 cycles |
| Cycle design life at 30% discharge | 1,800 cycles |
| Chemistry | Lead-acid |
| Cold crancking amps (CCA) at -18°C (0°F) | 250 A |
| Capacity C5 (10,8V) | 85 % |
| Capacity C20 (10,8V) | 100 % |
| Capacity C10 (10,8V) | 92 % |
| Voltage | 12V |
| Power Source | Battery |
| Manufacturer Part Number (MPN) | BAT412550104 |
