This high quality, waterproof 150W folding solar panel is designed to provide free power for charging 12V/24V batteries, for example in vehicles and boats (motorhome, caravan, camper, narrow boat, yacht etc) or any other system with a 12V/24V battery or battery bank. This is the ideal solution for experiencing the benefits of solar without the permanency of a mounted solar panel, as this panel can be folded and stored away when not in use.
More Information
- Peak power: 150W
- Maximum power voltage: 17.5V
- Maximum power current: 8.32A (2 x 4.16A)
- Open circuit voltage: 21.6V
- Short circuit current: 9.0A (2 x 4.5A)
- Power allowance: +/- 3%
- Dimensions: 51 x 101 x 7 cm (folded)
- Weight: 15kg
Technical Specification
This product is covered by a 1 year workmanship warranty.
In addition, solar cells are guaranteed to produce at least 90% of nominal power in 10 years after purchase and at least 80% of nominal power in 25 years after purchase. This warranty is provided by the manufacturer of solar cells.
120W Spec
Solar panel specifications:
- Peak power: 120W
- Maximum power voltage: 17.5V
- Maximum power current: 6.86A (2 x 3.43A)
- Open circuit voltage: 21.6V
- Short circuit current: 7.4A (2 x 3.7A)
- Power allowance: +/- 3%
- Cable: 5m 4.0mm2 single core solar cable
- Dimensions: 51 x 77 x 7 cm (folded)
- Weight: 12.8kg
150W Spec
Solar panel specifications:
- Peak power: 150W
- Maximum power voltage: 17.5V
- Maximum power current: 8.32A (2 x 4.16A)
- Open circuit voltage: 21.6V
- Short circuit current: 9.0A (2 x 4.5A)
- Power allowance: +/- 3%
- Dimensions: 51 x 101 x 7 cm (folded)
- Weight: 15kg
