Blue Print Brake Disc - Front Axle
This Blue Print Brake Disc (Part Number: ADB1143114) is designed for the Front Axle position and is manufactured to OE-quality standards for reliable performance and exact fitment.
These products are designed to be used as originally intended and not modified for purpose. Please ensure the products are installed by a competent individual. N.B. products are usually supplied without fitting instructions.
Vehicle Compatibility
| Make | Model | Year | Type | Variant | Engine | Notes |
|---|---|---|---|---|---|---|
| Bmw | Z4 Roadster (E89) | 2010-2016 | Convertible | sDrive 35 is | 250KW 340HP | IMPORTANT: Check measurements & dimensions as variations exist |
| Bmw | Z4 Roadster (E89) | 2009-2016 | Convertible | sDrive 35 i | 225KW 306HP | IMPORTANT: Check measurements & dimensions as variations exist |
↔ Swipe to see more columns on mobile
Specifications
| Part Number | ADB1143114 |
| Brake Disc Thickness [mm] | 30 |
| Rim Hole Number | 5 |
| Number of mounting bores | 1 |
| Thickness [mm] | 73 |
| Outer Diameter [mm] | 348 |
| Bolt Hole Circle Ø [mm] | 120 |
| Processing | High-carbon |
| Surface | Coated |
| Brake Disc Type | internally vented |
| Fitting Position | Front Axle |
| Minimum thickness [mm] | 28.4 |
| Centering Diameter [mm] | 79 |
| EAN / Barcode | 5057746132644 |
OEM Cross References (1)
