Victron Smart BatteryProtect 48V-100A
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
Disconnect the battery from non-essential loads before it is completely discharged with Victron Energy's Smart BatteryProtect. This device is designed to protect your battery and ensure longevity by managing the load and disconnection effectively.
It features a remote on/off terminal and can handle a maximum continuous load current rating of 100 A at 40°C, making it suitable for various applications. The Smart BatteryProtect also includes Bluetooth connectivity for easy monitoring and control.
With an operating voltage range of 44 to 64 V and an operating temperature range from -40 to 50 °C, this product is built to withstand challenging environments. The IP67 protection category for electronic components ensures durability against dust and moisture.
Key Features
- Bluetooth connectivity for remote monitoring
- Maximum continuous load current rating of 100 A
- Operating voltage range: 44-64 V
- IP67 protection for electronic components
- Alarm output and remote terminal included
Specifications
| Brand | Victron |
| EAN | 8719076041252 |
| Type | Power Product |
| Sub-Type | other |
| Custom Bundle | No |
| Alarm Terminal | Screw terminal 3-pole |
| Battery and Load Terminals | M8 bolts |
| Remote Terminal | Screw terminal two pole |
| Item Depth | 164 mm |
| Item Height | 61 mm |
| Protection category connection area | IP00 |
| Protection category electronic components | IP67 |
| Weight | 0.5 kg |
| Item Width | 41 mm |
| Able to deal with reverse current | No |
| Maximum continuous load current rating up to 60°C | 60 A |
| Remote On Off Terminal | True |
| Protections | Output short-circuit |
| Peak current rating (30 seconds) | 600 A |
| Operating voltage range | [44, 64] V |
| Operating temperature range | [-40, 50] °C |
| Maximum load on alarm output | 50 mA |
| Load disconnect delay (immediate if triggered by the VE.Bus BMS) | 90 s |
| Current consumption when off or in low volate protection mode (Bluetooth on) | 0.9 mA |
| Load reconnect delay | 30 s |
| Default threshold engage at 24V | 24 V |
| Default threshold engage at 12V | 12 V |
| Default threshold disengage at 24V | 21 V |
| Default threshold disengage at 12V | 10.5 V |
| Current consumption when on (Bluetooth off) | 1.2 mA |
| Current consumption when on (Bluetooth on) | 1.4 mA |
| Current consumption when off or in low volate protection mode (Bluetooth off) | 0.7 mA |
| Maximum continuous load current rating up to 40°C | 100 A |
| Bluetooth | Yes |
| Battery voltage nominal | 48V |
| Alarm output delay | 12 s |
| Voltage | 48V |
| Manufacturer Part Number (MPN) | BPR110048000 |
Downloads
- 1.6Kva 12V Multiplus 230V 2X150Ah Ng Li Vebus Bms Ng Bmv Cerbo Gx Touch 50 Sbp 2
- 3 Phase 5Kw24V Quattro Ii System Vebus Bms 2Xsbp 4X200Ah Li Cerbo Gx Touch 50 Mp
- 3 Phase Ve Bus Bms System 5 Pin With 3Xquattro And 4X200Ah 24V Li Rev C1
- Brochure Marine En 2025
- Brochure Off Grid Backup And Island Systems 2025 En Web
- Datasheet Smart Battery Protect 65 A 100 A 220 A En
