Bosch Main Power Relay
Free returns on all eligible orders
You have 30 days to request a return. All sale items are final sale.
Shipping information
Use this text to share information about your product.
Returns & warranty
Use this text to share information about your product.
Description
This Bosch Relay, main current (Part Number 0 332 209 204) is OE-quality replacement, supplied for direct fitment to compatible vehicles.
Specifications
| Brand | Bosch |
|---|---|
| Part Type | Relay, main current |
| Current Strength | 20A |
| Voltage | 24V |
| Number of pins | 5 |
| Relay function | Normally open contact |
| Housing Type | Synthetic Material Housing |
| Switch Function | Changeover Contact |
| Protection Type (IP Code) | IP5K4 |
| Temperature range from | -40°C |
| Temperature range to | 85°C |
| Resistor | 32Ohm |
| Supplementary Article/Supplementary Info | without holder |
| Housing Colour | black/grey |
| Manufacturer Part Number | 0 332 209 204 |
Vehicle Compatibility
Use the vehicle compatibility checker above to confirm fitment to your registration. This part fits the following vehicles:
No vehicle compatibility data available for this part.
OEM References
This part is a direct OE-quality replacement for the following original equipment manufacturer part numbers:
| Make | Reference |
|---|---|
| Aebi | 0183450185 |
| Atlas Copco | 8302329 |
| Case Ih | 71403888, 84302762, 8464780 |
| DAF | 0067378, 1519524, 867518 |
| Daimler | A0035459805, A0045456405 |
| Faun | EA4052, 5162 372, 5241 920 |
| Hanomag Henschel | 5945121597938 |
| Iveco | 1172393, 5006143961 |
| Komatsu | 20K0632130, 4901665M |
| Krone | 505821657 |
| Liebherr | 630 121 508 |
| Linde | 7916295101 |
| MAN | 81 25902 6005, 88 25902 6005 |
| Mafi | 0005790730 |
| Magirus-Deutz | 04194494, 419 4494 |
| Mercedes-Benz | A 000 545 58 05, A 003 545 98 05, A 004 545 11 05, A 004 545 33 05, A 004 545 64 05, A 004 545 78 05, 000 545 58 05, 003 545 98 05, 004 545 11 05, 004 545 33 05, 004 545 64 05, 004 545 78 05 |
| O&K | 84302762 |
| Paus | 575570 |
| Renault | 50 00 287 954, 50 06 143 961, 50 10 306 869, 50 10 306 907 |
| Renault Trucks | 50 06 143 961, 50 10 207 197 |
| Rosenbauer | FE8137, 81330 |
| Schmitz Cargobull | 063488 |
| Steinbock | 51139816 |
| Terex | 5050247337, 8302329 |
| Volvo | 21244697, 4786690, 70343715, 9518230 |
Why Buy Bosch?
Bosch is a trusted name in OE-quality replacement parts. Every component is manufactured to original equipment standards, providing reliable performance, exact fitment and long service life.
- OE-quality construction
- Tested to manufacturer specifications
- Trusted by professional workshops
- Backed by manufacturer warranty
